| Property | Unit | Value | Test Method |
|---|---|---|---|
| Temperature range | °C | (-50 - 110) | GB/T 17794-1999 |
| Density range | Kg/m³ | 45-65Kg/m³ | ASTM D1667 |
| Water vapor permeability | Kg/(m.s.pa) | ≤0.91×10⁻¹³ | DIN 52 615 / BS 4370 Part 2 1973 |
| μ | - | ≥10000 | - |
| Thermal Conductivity | W/(m.k) | ≤0.030 (-20°C) | ASTM C 518 |
| ≤0.032 (0°C) | |||
| ≤0.036 (40°C) | |||
| Fire Rating | - | Class 0 & Class 1 | BS 476 Part 6 part 7 |
| Flame Spread and Smoke Developed Index | - | 25/50 | ASTM E 84 |
| Oxygen Index | - | ≥36 | GB/T 2406, ISO4589 |
| Water Absorption, % by Volume | % | 20% | ASTM C 209 |
| Dimension Stability | - | ≤5 | ASTM C534 |
| Fungi resistance | - | Good | ASTM 21 |
| Ozone resistance | Good | GB/T 7762-1987 | |
| Resistance to U.V. and weather | Good | ASTM G23 |
1. What is an insulation product?
Insulation products are used to cover pipes, ducts, tanks, and equipment in commercial or industrial environments. They are typically relied upon to control temperature for a much broader range of temperature variances than that of a typical home. Home or residential insulation is commonly found in exterior walls and attics to maintain a consistent, comfortable living environment, where the temperature differential is far less than in typical commercial or industrial applications.
2. What is the standard lead time for orders?
For bulk goods orders, the production and delivery timeframe will be within three weeks after receiving the down payment.
3. How are the products tested?
Our materials are normally tested under recognized standards such as BS476, DIN5510, CE, REACH, ROHS, and UL94 at independent testing laboratories. For specific requests or custom test requests, please consult the technical manager.
4. What type of enterprise model is operated?
The business operates as an integrated enterprise combining manufacturing industry capabilities and trade services.
5. What are the main products available?
The core product range includes NBR/PVC rubber foam insulation, glass wool insulation, and a complete line of insulation accessories.
6. What packing options are available for the insulation tubes?
The products can be packaged using export standard carton packages, export standard plastic bags, or customized packages tailored to specific client requirements.
