China Elastomeric Insulation For Ultra Low Temperature System Manufacturers, Factory
Kingflex flexible ultra-low temperature insulation system belong to the multi-layer composite structure, is the most economical and reliable cooling system.
The system can be directly installed under the temperature as low as -110℃ on all piping equipment when the surface temperature of the pipe is lower than -100℃ and the pipeline usually has obvious repeated movement or vibration, it is necessary to a layer of wear-resistant film is laid on the inner surface to further strength the inner wall strength of the material to ensure the long-term adiabatic effect of frequent movement and vibration of the process pipeline under deep cooling.
ULT Technical Data
Property
Unit
Value
Temperature range
°C
-200 to +110
Density range
Kg/m³
60-80 Kg/m³
Thermal Conductivity
W/(m.k)
≤0.028 (-100°C)
≤0.021 (-165°C)
Fungi resistance
-
Good
Ozone resistance
-
Good
Resistance to U.V. and weather
-
Good
Performance Highlights & Benefits
Low thermal conductivity for excellent energy efficiency.
Low glass transition temperature ensuring stability in extreme cold.
Easy and efficient installation even for complex geometrical shapes.
Fewer joints to guarantee airtightness and enhance installation speed.
Highly competitive comprehensive cost for project budget savings.
Built-in moisture proofing, eliminating the need for extra moisture barriers.
Eco-friendly formulation: free of fiber, dust, CFCs, and HCFCs.
No expansion joints required, streamlining design and system integration.
Frequently Asked Questions (FAQ)
What is the operating temperature range for this insulation system?
The system features an operating temperature range of -200°C to +110°C, and can be directly installed at temperatures as low as -110°C on active piping equipment.
How does the system handle frequent vibration and movement?
When pipe surface temperatures fall below -100°C and experience repetitive movement or vibration, a wear-resistant film is applied to the inner surface. This layer strengthens the inner wall of the material to ensure long-term, reliable adiabatic performance under cryogenic conditions.
What are the thermal conductivity properties of the material?
The material delivers low thermal conductivity rates, tested at ≤0.028 W/(m.k) at -100°C and ≤0.021 W/(m.k) at -165°C, ensuring optimal energy conservation.
Is an additional moisture barrier required during installation?
No, the insulation comes with a built-in moisture proof structure. An additional vapor or moisture barrier is not required, simplifying the setup process and reducing installation costs.
Is this insulation system safe and environmentally friendly?
Yes. The material is formulated without fibers, dust, CFCs, or HCFCs, making it safe to handle and environmentally compliant.
Does the insulation system exhibit good environmental resistance?
Yes, the system demonstrates excellent resistance to fungi, ozone, ultraviolet (U.V.) light, and severe weather conditions.
