China Foam rubber thermal insulation sheet roll Manufacturers, Suppliers

Kingflex soft rubber insulation products have such perfect performances as soft, anti-bending, cold-resistant, heat-resisting, fire-blocking, water-proof, low thermal conductivity, shake-reduction and sound-absorption. And every performance index is better than national standard.

Send Inquiry

Product Description

This high-performance thermal insulation material utilizes butyronitrile rubber and polyvinyl chloride (NBR/PVC) as the main raw materials. Manufactured through advanced foaming and specialized procedures, it forms a soft, closed-pore foaming heat-insulating structure. Formulated entirely without Chlorofluorocarbons (CFC) and Formaldehyde, it delivers lasting and stable thermal conductivity performance alongside superior fire protection (oxygen index ≥ 40%). Recognized for its anti-cracking properties, high elasticity, and broad temperature endurance, its outstanding corrosion resistance prevents premature aging, ensuring a simplified installation process and an extended service lifespan.

Eco-Friendly Formulation

Zero Chlorofluorocarbon (CFC) and Formaldehyde content ensures safe application and environment protection.

High Fire Resistance

High-level flame retardant capabilities featuring an oxygen index of 40% or higher.

Exceptional Durability

High elasticity combined with cracking resistance and stable thermal parameters over time.

Product Presentation

Dimensions & Packaging

Thickness		Width 1m		Width 1.2m		Width 1.5m
Inches	mm	Size(L*W)	㎡/Roll	Size(L*W)	㎡/Roll	Size(L*W)	㎡/Roll
1/4"	6	30 × 1	30	30 × 1.2	36	30 × 1.5	45
3/8"	10	20 × 1	20	20 × 1.2	24	20 × 1.5	30
1/2"	13	15 × 1	15	15 × 1.2	18	15 × 1.5	22.5
3/4"	19	10 × 1	10	10 × 1.2	12	10 × 1.5	15
1"	25	8 × 1	8	8 × 1.2	9.6	8 × 1.5	12
1 1/4"	32	6 × 1	6	6 × 1.2	7.2	6 × 1.5	9
1 1/2"	40	5 × 1	5	5 × 1.2	6	5 × 1.5	7.5
2"	50	4 × 1	4	4 × 1.2	4.8	4 × 1.5	6

Technical Specifications

Property	Unit	Value	Test Method
Temperature range	°C	-50 to 110	GB/T 17794-1999
Density range	Kg/m3	45-65	ASTM D1667
Water vapor permeability	Kg/(m.s.pa)	≤0.91×10⁻¹³	DIN 52 615 / BS 4370 Part 2 1973
μ (Water vapor diffusion resistance)	-	≥10000	-
Thermal Conductivity	W/(m.k)	≤0.030 (-20°C)	ASTM C 518
		≤0.032 (0°C)
		≤0.036 (40°C)
Fire Rating	-	Class 0 & Class 1	BS 476 Part 6 & Part 7
Flame Spread and Smoke Developed Index	-	25/50	ASTM E 84
Oxygen Index	-	≥36	GB/T 2406, ISO 4589
Water Absorption, % by Volume	%	≤2%	ASTM C 209
Dimension Stability	%	≤5	ASTM C534
Fungi resistance	-	Good	ASTM G21
Ozone resistance	-	Good	GB/T 7762-1987
Resistance to U.V. and weather	-	Good	ASTM G23

Thermal Insulation Foam Roll in Warehouse

Frequently Asked Questions

QWhat are the main raw materials used in this thermal insulation material?

The insulation material is principalmente composed of butyronitrile rubber and polyvinyl chloride (NBR/PVC), processed through special foaming procedures to form a closed-pore structure.

QIs this product environmentally safe?

Yes. It is manufactured without the use of Chlorofluorocarbon (CFC) and Formaldehyde, making it an eco-friendly choice for mechanical insulation projects.

QWhat is the operating temperature range for this insulation?

The material exhibits excellent stability across a temperature range from -50°C up to 110°C, proving highly resistant to both freezing and hot conditions.

QWhat are the fire safety performance ratings?

The product features an oxygen index of ≥40% (with a minimum baseline of ≥36 according to standard tests) and achieves a Class 0 and Class 1 fire rating compliant with BS 476 Part 6 & Part 7.

QDoes the material resist moisture and biological growth?

Yes. It features a water vapor permeability of ≤0.91×10⁻¹³ Kg/(m.s.pa), a diffusion resistance index (μ) of ≥10000, and is rated "Good" for both fungi and ozone resistance.
