| Property |
Unit |
Value |
Test Method |
| Temperature range |
°C |
-50 to 110 |
GB/T 17794-1999 |
| Density range |
Kg/m³ |
45-65 |
ASTM D1667 |
| Water vapor permeability |
Kg/(m.s.pa) |
≤0.91×10⁻¹³ |
DIN 52 615 / BS 4370 Part 2 1973 |
| μ |
- |
≥10000 |
- |
| Thermal Conductivity |
W/(m.k) |
≤0.030 (-20°C)
≤0.032 (0°C)
≤0.036 (40°C)
|
ASTM C 518 |
| Fire Rating |
- |
Class 0 & Class 1 |
BS 476 Part 6 & Part 7 |
| Flame Spread and Smoke Developed Index |
- |
25/50 |
ASTM E 84 |
| Oxygen Index |
- |
≥36 |
GB/T 2406, ISO4589 |
| Water Absorption, % by Volume |
% |
20% |
ASTM C 209 |
| Dimension Stability |
- |
≤5 |
ASTM C534 |
| Fungi resistance |
- |
Good |
ASTM 21 |
| Ozone resistance |
- |
Good |
GB/T 7762-1987 |
| Resistance to U.V. and weather |
- |
Good |
ASTM G23 |
Key Performance Advantages
- ✓Excellent fire-resistance performance & Sound absorption: High safety rating ensures top-tier flame retardancy and noise dampening.
- ✓Low thermal conductivity (K-Value): Delivers exceptional insulation performance to reduce heat transfer.
- ✓Good moisture resistance: Protects against moisture accumulation and keeps structural integrity.
- ✓Environmentally friendly: Manufactured without harmful chemicals, safe for green building standards.
- ✓Easy to install & Nice appearance: Highly flexible for quick, clean aesthetics on any pipeline configuration.
Product Structural Benefits
- ✓Closed-cell structure provides excellent condensation and energy-loss control.
- ✓Effectively retards degradation due to ultraviolet (UV) radiation.
- ✓Flexible material with dusted, relaxed ID’s for easy installation.
- ✓Superior toughness to withstand demanding on-site handling.
- ✓Built-in vapor barrier eliminates the need for an additional vapor retarder.
- ✓Complete size range available for HVAC/R applications.
- ✓Distinguish between different pipelines effortlessly during project layout.
Product Showcase
Frequently Asked Questions
What is the operating temperature range of this elastomeric foam insulation?
This material operates safely and effectively within a temperature range of -50°C to 110°C, tested in compliance with GB/T 17794-1999 standards.
What are the fire resistance ratings of this product?
The elastomeric insulation features Class 0 and Class 1 fire ratings according to BS 476 Part 6 & Part 7, alongside a Flame Spread and Smoke Developed Index of 25/50 under ASTM E 84.
Does this insulation require an additional vapor barrier?
No, the built-in closed-cell structure operates as an inherent vapor barrier, which eliminates the necessity and cost of installing an external vapor retarder.
How does the insulation handle UV and environmental weathering?
It offers excellent UV and ozone resistance, tested under ASTM G23 and GB/T 7762-1987, which protects the material from premature degradation in exterior conditions.
What is the thermal conductivity (K-Value) of the material?
The material exhibits very low thermal conductivity: ≤0.030 W/(m.k) at -20°C, ≤0.032 W/(m.k) at 0°C, and ≤0.036 W/(m.k) at 40°C, ensuring optimal energy conservation.
Is this product resistant to mold and fungal growth?
Yes, it has been certified with "Good" fungi resistance under ASTM 21 standards, making it highly suitable for clean air environments and HVAC/R systems.
