Wholesale Elastomeric cryogenic insulation for Ultra Low Temperature System Manufacturers, Factories

Global demand for liquefied natural gas (LNG) is rising. High-performance technology is required for reliable transport and storage. Engineers have to develop plants that are safe and efficient. The extremely low temperature，at which natural gas is in a liquid state, places high demands on the technical infrastructure throughout the entire value chain of LNG. All the plant components and systems coming into contact with the liquefied gas have to be extremely well insulated.

Send Inquiry

Product Description

Flexible Ultra-low Temperature Insulation

Impact & Vibration Resistance

The flexible ultra-low temperature adiabatic system possesses inherent impact resistance. Its advanced cryogenic elastomer material absorbs external mechanical impact and vibration energy effectively to safeguard the structural integrity of your system.

Built-in Vapor Barrier

Equipped with an integrated vapor barrier, this system significantly extends the operating lifespan of the entire cold insulation configuration while substantially minimizing the risks of under-insulation corrosion on pipework.

Built-in Expansion Joint

The flexible ULT insulation design features built-in expansion joints, eliminating the need to install external fiber materials as expansion or compression fillers.

Key Applications

Liquefied Natural Gas (LNG); Large-scale cryogenic storage tanks; PetroChina & SINOPEC ethylene projects; Nitrogen plants; Coal chemical industries, and related industrial infrastructures.

ULT Technical Data
Property	Unit	Value
Temperature range	°C	(-200 to +110)
Density range	Kg/m³	60 - 80 Kg/m³
Thermal Conductivity	W/(m.k)	≤ 0.028 (-100°C)
Thermal Conductivity	W/(m.k)	≤ 0.021 (-165°C)
Fungi resistance	-	Good
Ozone resistance	-	Good
Resistance to U.V. and weather	-	Good

Frequently Asked Questions (FAQ)

What are the key benefits of using this flexible ultra-low temperature adiabatic system?

The system features excellent impact and vibration resistance due to its cryogenic elastomer materials. It also has a built-in vapor barrier to extend lifespan and reduce corrosion under insulation (CUI), along with built-in expansion joints that eliminate the need for traditional fiber fillers.

What is the safe operating temperature range for the ULT insulation material?

The material is certified to operate reliably within an ultra-low temperature window spanning from -200°C up to +110°C, making it ideal for deep cryogenic services.

Why is a built-in vapor barrier critical for cold insulation systems?

A built-in vapor barrier prevents moisture ingress, which can lead to ice formation and subsequent loss of insulation performance. This protection substantially extends the system's operational life and minimizes pipe corrosion beneath the insulation layer.

What are the thermal conductivity properties of this insulation system?

The system demonstrates low thermal conductivity values: ≤0.028 W/(m.k) at -100°C and ≤0.021 W/(m.k) at -165°C, ensuring optimal thermal efficiency at extreme temperatures.

How does this insulation system perform against environmental factors like UV or fungi?

The technical data shows that this ULT insulation material offers good resistance to fungi, ozone, ultraviolet (U.V.) light, and severe weather exposure, making it highly durable for diverse environmental conditions.
