The ultra-low temperature protection system of diolefin and butadiene rubber is a high-performance elastic foaming developed by us specifically for the insulation project under ultra-low temperature conditions.Reducing temperature variation stress is one of the important features of the system over traditional rigid foam insulation materials such as foam glass, polyurethane PIR and PUR.
Our flexible ultra-low temperature insulation system does not require a moisture barrier. Thanks to the unique closed cell structure and polymer mix formula, the elastic foam material of nitrile butadiene rubber has a high resistance to water vapor penetration. This foam material provides continuous resistance to moisture penetration throughout the thickness of the product.
ULT Technical Data
Property
Unit
Value
Temperature range
°C
(-200 to +110)
Density range
Kg/m³
60-80Kg/m³
Thermal Conductivity
W/(m.k)
≤0.028 (-100°C)
≤0.021 (-165°C)
Fungi resistance
-
Good
Ozone resistance
-
Good
Resistance to U.V. and weather
-
Good
Growth in the construction industry and many other industrial segments, combined with concerns over rising energy costs and noise pollution, is fueling market demand for thermal insulation. With more than four decades of dedicated experience in manufacturing and applications, our thermal insulation solutions are continuously optimized to meet rising market demands.
With 5 large automatic assembly lines and more than 600,000 cubic meters of annual production capacity, our production facility is designated as a qualified manufacturing enterprise of thermal insulation materials for major energy, electric power, and chemical industry departments.
Key Features
No built-in moisture barrier is required
No built-in expansion joint
Temperature range: -200℃ to +125℃
Remains highly elastic at extremely low temperatures
Applications
Coal chemical MOT
Low temperature storage tanks & LNG systems
FPSO floating production storage oil unloading devices
Industrial gas and agricultural chemical production plants
Platform piping & gas stations
Ethylene piping & nitrogen plants
Frequently Asked Questions
1. Does this low-temperature insulation system require a moisture barrier?
No. Thanks to its unique closed-cell structure and polymer mix formula, the elastomeric foam material offers extremely high resistance to water vapor, eliminating the need for an external moisture barrier.
2. What is the certified operating temperature range?
The system operates reliably in extreme temperatures ranging from -200°C up to +125°C, maintaining its physical properties and flexibility.
3. What is the thermal conductivity of this insulation material?
The thermal conductivity is exceptionally low: ≤0.028 W/(m.k) at -100°C and ≤0.021 W/(m.k) at -165°C, ensuring optimal energy conservation.
4. How does the material behave at extremely low temperatures?
The elastomeric foam is specifically engineered to remain flexible and elastic even under cryogenic conditions, meaning no expansion joints are required during installation.
5. Is the material resistant to weathering and outdoor elements?
Yes, the insulation displays excellent resistance to ozone, ultraviolet (U.V.) rays, general weathering, and fungi growth, making it highly durable for industrial outdoor environments.
6. What primary industries utilize this insulation solution?
It is widely used in LNG piping and storage tanks, ethylene facilities, coal chemical MOT plants, nitrogen systems, FPSO platforms, and industrial gas production sites.
