Home > Rubber Foam Insulation Products > Wholesale Kingflex foam rubber pipe insulation Supplier, Factory
Wholesale Kingflex foam rubber pipe insulation Supplier, Factory
Wholesale Kingflex foam rubber pipe insulation Supplier, Factory
Wholesale Kingflex foam rubber pipe insulation Supplier, Factory
1 / 3
Wholesale Kingflex foam rubber pipe insulation Supplier, Factory
Wholesale Kingflex foam rubber pipe insulation Supplier, Factory
Wholesale Kingflex foam rubber pipe insulation Supplier, Factory

Wholesale Kingflex foam rubber pipe insulation Supplier, Factory

What is Elastomeric Foam Insulation? Essentially, elastomeric foam insulation is a synthetic rubber composed of a closed-cell structure available in factory-made tubes, sheets, or rolls. The outside edge consists of a smooth surface or “skin” which serves as a built-in vapor retarder. Due to elastomeric foam’s flexible nature, it is less susceptible to cracks, breakage, and material loss when compared to rigid insulation options such as cellular glass, polyiso and phenolic foam. Finally, it’s also fiber-free and low-VOC for chemical emissions.阿
Send Inquiry

Product Description

Dimension Specifications
Thickness Width 1.0m Width 1.2m Width 1.5m
Inches mm Size (L*W) ㎡/Roll Size (L*W) ㎡/Roll Size (L*W) ㎡/Roll
1/4" 6 30 × 1 30 30 × 1.2 36 30 × 1.5 45
3/8" 10 20 × 1 20 20 × 1.2 24 20 × 1.5 30
1/2" 13 15 × 1 15 15 × 1.2 18 15 × 1.5 22.5
3/4" 19 10 × 1 10 10 × 1.2 12 10 × 1.5 15
1" 25 8 × 1 8 8 × 1.2 9.6 8 × 1.5 12
1 1/4" 32 6 × 1 6 6 × 1.2 7.2 6 × 1.5 9
1 1/2" 40 5 × 1 5 5 × 1.2 6 5 × 1.5 7.5
2" 50 4 × 1 4 4 × 1.2 4.8 4 × 1.5 6
Technical Specifications
Property Unit Value Test Method
Temperature range °C (-50 - 110) GB/T 17794-1999
Density range Kg/m³ 45-65Kg/m³ ASTM D1667
Water vapor permeability Kg/(m.s.pa) ≤0.91×10⁻¹³ DIN 52 615 / BS 4370 Part 2 1973
μ - ≥10000 -
Thermal Conductivity W/(m.k) ≤0.030 (-20°C) ASTM C 518
Thermal Conductivity W/(m.k) ≤0.032 (0°C) ASTM C 518
Thermal Conductivity W/(m.k) ≤0.036 (40°C) ASTM C 518
Fire Rating - Class 0 & Class 1 BS 476 Part 6 part 7
Flame Spread and Smoke Developed Index - 25/50 ASTM E 84
Oxygen Index - ≥36 GB/T 2406, ISO4589
Water Absorption, % by Volume % 20% ASTM C 209
Dimension Stability - ≤5 ASTM C534
Fungi resistance - Good ASTM G21
Ozone resistance - Good GB/T 7762-1987
Resistance to U.V. and weather - Good ASTM G23
Insulation Material Overview
As a leading manufacturer nowadays we supply more than half of the region's requirements for rubber insulation products, and trade in the complete range of insulation products.
  • ✓ Cleaner and safer
  • ✓ Long life time & High Flammability
  • ✓ High anti-corrosive properties
  • ✓ Good water resisting property
  • ✓ Top grade appearance
Product Gallery
Insulation Product 1
Insulation Product 2
Insulation Product 3
Insulation Product 4
Insulation Product 5
Insulation Product 6
Insulation Product 7
Insulation Product 8
Insulation Product 9
Insulation Product 10
Insulation Product 11
Frequently Asked Questions (FAQ)
What is the operating temperature range for these rubber insulation products?
Our rubber insulation products are designed to operate efficiently within a temperature range of -50°C to 110°C, making them highly versatile for various industrial and commercial systems.
What fire ratings does the insulation material achieve?
The material is highly fire-resistant, meeting Class 0 & Class 1 fire ratings under the BS 476 Part 6 & Part 7 test standards. It also features a low smoke and flame spread index of 25/50 according to ASTM E 84.
How does this rubber insulation perform against water and moisture?
It offers exceptional water resistance with a high water vapor permeability resistance value (μ ≥ 10,000) and low water absorption of 20% by volume. This prevents moisture accumulation and protects underlying systems.
Are these insulation products resistant to environmental factors like UV and Ozone?
Yes. The technical specifications indicate good resistance to UV rays, weathering, and ozone under ASTM and GB testing standards, ensuring durability in diverse outdoor climates.
What size and thickness configurations are available?
We supply rolls with thicknesses ranging from 1/4" (6mm) to 2" (50mm). Width options include standard 1.0m, 1.2m, and 1.5m widths to accommodate different duct and pipe dimensions.
Is this insulation material resistant to mold and fungal growth?
Yes, the material exhibits excellent fungi resistance tested under the ASTM G21 standard, ensuring a cleaner, safer, and mold-free environment.
