Industry and Building industry (shell of big tanks and piping in the construction)
Pipe insulation
Air conditioning units
Sound insulation/absorption system
Protection of sports equipment, in cushions and diving suits
Every kind of cold/hot medium piping and containers
NBR PVC Rubber foam insulation material Product advantage:
Close-cell structure, smooth surface, light weight, easy to cut convenient installation, fast construction.
High quality rubber foam insulation material reduce heat loss, save the energy, waterproof, with low thermal conductivity and also keeps the process temperature stable.
With strong adhesive on the back, with high concentration coating, stronger viscosity, durable.
Various sizes meet construction requirements.
Various veneer to protect the material, scratch and pressure resistant.
Waterproof, B1 Class flame retardant.
The product section is neat, the thickness is even, the material is flexible and elastic, smooth and flat.
Frequently Asked Questions
1. What is the temperature range that this rubber foam insulation can withstand?
This NBR PVC rubber foam insulation operates efficiently within a temperature range of -50°C to 110°C, tested in compliance with GB/T 17794-1999 standards.
2. How is the thermal conductivity of this insulation material classified?
The material exhibits excellent thermal insulation properties. According to ASTM C 518 standards, the thermal conductivity values are ≤0.030 W/(m.k) at -20°C, ≤0.032 W/(m.k) at 0°C, and ≤0.036 W/(m.k) at 40°C.
3. Does the insulation material meet fire safety standards?
Yes, it achieves a Class 0 & Class 1 Fire Rating under BS 476 Part 6 & Part 7 test standards. It also achieves an oxygen index of ≥36 (GB/T 2406, ISO4589) and is B1 Class flame retardant.
4. What are the key applications for NBR PVC rubber foam?
It is widely used in industrial and building sectors for big tanks and piping, general pipe insulation, air conditioning units, sound insulation systems, protective padding for sports equipment/diving suits, and all types of hot or cold medium containers.
5. What makes the self-adhesive backing design advantageous for installations?
The product is designed with a strong adhesive on the back featuring a high-concentration coating. This provides a stronger viscosity, ensures long-lasting durability, and enables quick, easy installation during construction.
6. What dimensions and thicknesses are available for the rolls?
The product comes in thicknesses ranging from 1/4" (6mm) up to 2" (50mm). Width options are available in 1m, 1.2m, and 1.5m to suit diverse project requirements and reduce waste.
